OXFORD S-MIG 270-1

Synergic MIG, Transformer, Wire Feeder, 220A@45%, 230V (20A-32A)

This rugged built welder from renowned British manufacturer Oxford, with high reliability, excellent welding performance, and long lifespan is made to last. With a mixture of modern components and good old fashioned quality engineering; a copper wound main transformer, rugged switchgear, over rated rectifier and fan, and a simple, robust PCB. This welder will withstand dusty, or damp dirty workshops much better than modern inverter type welders.

A synergic welder with a separate wire feed unit. Suitable for light and medium fabrication / agricultural jobs, and ideal for farmers, fabricators, etc looking for a large capacity single phase welder on a 32A supply. This welder is also suitable for automotive work as the current can go as low as 20A, making it possible to weld the thinnest car panels. Oxford cap+ technology ensures a smooth weld on all materials including stainless steel, aluminium etc. A robust PCB gives precise control for super smooth speed control, motor braking and burn back (internal adjustment possible). Synergic controls make it easy to set up and use. This welder is also energy efficient giving lower running costs.

  • ● Manufacturer: OXFORD
  • ● Model: S-MIG 270-1
  • ● Manufactured in the UK
  • ● Copper Wound Transformer
  • ● Supplied with Separate Wire Feed Unit
  • ● 2-Roller Wire Feed
  • ● Synergic Control of Wire Feed
  • ● Torch Trigger Latching

  2 years machine warranty
  5 years main transformer warranty
  Guaranteed spares availability for 20 years minimum



R098.6221 synergic mig welder

Specifications
Supply Voltage230V
Fuse Rating (slow blow)32A at full power
20A at 3/4 power
Min Generator Size5.5KVA for 3/4 power
7.7KVA for full power
Output Current20A - 270A
Voltage Steps16
MIG wire range0.6 - 1.2mm
No of Inductance Settings1
Intercon Lead Length5m standard
Approx Weight80kg
Duty Cycle
@ 45%220A
@ 60%190A

Welder is supplied with :-
- Earth Lead
- Gas Hose
- 1.0-1.2mm V-groove wire feed roller

Optional accessories available are :-
- Gas Regulator
- MIG Euro-Torches
- Different Wire Feed Rollers

Optional modifications are available (ask for details) :-
- Reverse Polarity Function (for welding with gasless wire)
- Spot Welding Timer
- Spool Cover
- Digital Meter Kit
- Calibration for EN1090
- Upgrade to 10m, 15m or 20m Intercon Leads
- Spool Guns
- Push-Pull Guns for

welder product code : R098.6221
for optional 3 metre MIG torch, see: R014.2214
for optional 4 metre MIG torch, see: R014.2215
for optional 5 metre MIG torch, see: R014.2216

for optional gas regulator, see: R014.2230

for spare wire feed rollers, see: Oxford Wire Feed Rollers



R098.6221

OXFORD S-MIG 270-1 - Synergic MIG, Transformer, Wire Feeder, 220A@45%, 230V (20A-32A)




£920.00 + VAT..... £1,104.00 (GBP)
